Range of product Modicon Quantum automation platform
Product or component type Unity processor
Complementary
Mode of transmission Multi mode
Clock frequency 266 MHz
Number of slots 10
16
4
6
2
Number of racks 2 – local
Number of distributed I/O station 63 1 3 Modbus Plus
Number of remote I/O station 31 – 2 S908 remote I/O
31 – 2 ethernet Quantum remote I/O
31 – 2 ethernet X80 remote I/O
Discrete I/O number 31744 inputs, 31744 outputs – remote
8000 inputs, 8000 outputs – distributed – per network Modbus Plus
Unlimited (31 drops of 28 slots max) – ethernet remote I/O
0 – local – forbidden in Hot Standby application
Analogue I/O number 500 inputs, 500 outputs – distributed – per network Modbus Plus
Unlimited (31 drops of 28 slots max) – ethernet remote I/O
1984 inputs,1984 outputs – remote
0 – local – forbidden in Hot Standby application
Application specific I/O Accurate time stamping
Counter
Serial link
High-speed interrupt inputs
Communication service Ethernet router
Number of optional modules 6 Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Maximum number of connections 1 USB
2 AS-Interface – distributed
4 AS-Interface – remote
6 Ethernet TCP/IP – local
6 Modbus Plus – local
6 Profibus DP – local
1 Modbus RS232/485 Modbus/ASCII)
Integrated connection type 1 Modbus Plus
1 Modbus
1 USB
1 optic fibre Hot Standby
Checks Process control
Hot standby
Memory description Expandable 7168 kB – program with PCMCIA card
Expandable 8 MB – file storage with PCMCIA card
Internal RAM 3072 kB – 1536 kB for data
Switch function Key switch memory port on/off
Application structure 1 periodic fast task – forbidden in Hot Standby application
128 I/O interrupt tasks – forbidden in Hot Standby application
128 interrupt tasks – forbidden in Hot Standby application
32 timer interrupt tasks – forbidden in Hot Standby application
4 auxiliary tasks – forbidden in Hot Standby application
1 cyclic/periodic master task –
Number of instructions per ms 10.28 Kinst/ms 100 % Boolean
10.07 Kinst/ms 65 % Boolean and 35 % numerical
System overhead 0.2 Ms fast task
1 Ms master task
Bus current requirement 2760 MA
Local signalling Ethernet activity (COM) 1 LED yellow)
Configuration status (STS) 1 LED yellow)
Electrical connection 1 female connector SUB-D 9 for connecting to the Modbus Plus network
1 connector RJ45 for connecting Modbus bus
1 connector MT-RJ (multimode fiber optic) for interconnecting primary and secondary PLCs up to 4 km
| 140CPU31110 |
| 140CPU43412U |
| 140CPU65150 |
| 140CPU65160 |
| 140CPU65260 |
| 140CPU65860 |
| 140CPU67060 |
| 140CPU67160 |
| 140CPU67260 |
| 140CPU67261 |
| 140CPU67861 |
| 140CPU65160S |
| 140CPU67160S |
| 140SDI95300S |
| 140SDO95300S |
| 140SAI94000S |
| 140XBP00300 |
| 140XBP00400 |
| 140XBP00600 |
| 140XBP01000 |
| 140XBP01600 |
| 140XBE10000 |
