3HAB2241-1 PLC control system module

3HAB2241-1  PLC control system module

ABB 3HAB2241-1 is a product for PLC control systems, with input and output functions, can be connected to the PLC input and output points, so as to achieve the control of the host input and output. At the same time, it can also be externally connected to other signal sources, and may be used with other system spare parts to meet the needs of industrial automation control.

Input unit: consists of 8 buttons, 8 switches and 16 connectors, which are connected to the 16 input points of the PLC. By changing the on/off state of these switches or buttons, the required number of switches can be entered into the host. In addition, the 16 connectors can also be external to other DC or switching input signals.
Output unit: consists of 24 diodes and 24 connectors, which are connected to 24 output points of the PLC. Some ground ends of the output unit (e.g. C4) are common with the 3V power supply.
Power supply and power: The power supply voltage of this product is 200v and the power is 1800.
Application scenario: In the PLC control system, the factory CPU module is equivalent to the human brain, continuously collecting input signals, executing user programs, and refreshing the output of the system. ABB 3HAB2241-1 as a system spare parts, may be used with DCS system card, PLC and all kinds of imported robot spare parts, servo controller, etc.
