The GE DS200SDCCG1AHD is a simplex servo I/O terminal board manufactured and designed by General Electric. It is part of the Mark VI series used in GE Speedtronic control systems and is also a GE drive control card with three microprocessors and RAM that can be accessed by multiple microprocessors at the same time. The board has two servo outputs, I/O for six LVDT position sensors, and two active pulse rate inputs for flow monitoring. It can select the servo coil current between 10 and 120mA via the jumper.
In addition, DS200SDCCG1AHD is also used in the steel industry industrial control DCS system gas turbine equipment. When in use, the board needs to be connected to a serial connector and linked to a laptop before it can be configured.

The technical parameters of GE DS200SDCCG1AHD include:
Size: 3020221
Range: 120-2101.
Accuracy: 0.1-0.5.
Control principle: DCS.
Working voltage: 230V.
Output frequency: 560kHz.
In addition, the DS200SDCCG1AHD has three main microprocessors, namely the drive control processor, the motor control processor and the linkage processor, and the RAM4, which can be accessed by multiple microprocessors at the same time. It also has 8 connectors including 1pl, 2pl, 3pl, 6pl, 7pl, 8pl, 9pl, and 11pl, but uses all connections except 9pl.
