IS200VSVOH1B VME servo control board
The IS200VSVOH1B is a powerful and reliable VME servo control board for the Mark VI series in gas turbine control systems. It supports the stable operation of the turbine by providing precise servo control and rich integrated functions.
The IS200VSVOH1B is a VME servo control board manufactured by General Electric (GE) and is part of the Mark VI family used in gas turbine control systems. Here are some of the main features and functions of the IS200VSVOH1B:
Application: IS200VSVOH1B is used as a servo control board for turbine control. It drives the fuel/steam valves by controlling four electro-hydraulic servo valves for precise turbine control.
Integrated functionality: The board provides pulse rate flow input, LVDT excitation, and LVDT position feedback to meet the various needs of turbine control systems.
System compatibility: The IS200VSVOH1B can be used in triple-redundant systems and simplex systems, providing a high degree of system flexibility and reliability.
Hardware design: The board has a single-slot front panel connected to the PCB that includes a cable connector (J5) and an LED indicator for status information. These indicators are usually not powered on when the power is off.
Software and Communications: Part of the Mark VI family, the IS200VSVOH1B integrates a PC-based operator interface and Ethernet communications for easier operation and maintenance.
Reliability and maintenance: IS200VSVOH1B is very reliable and not easily damaged. However, improper handling and storage may affect its functionality. Therefore, it is recommended to store the card in the electrostatic sensitive storage box under the recommended conditions and follow the appropriate ESD safety precautions for handling.
