IS210AEAAH1B VME communication interface card
The IS210AEAAH1B is a VME communication interface card manufactured by General Electric (GE) for use in the Mark VI series of gas turbine control systems.
Here are some of the main functions and features of the module:
Communication interface: The VME Bus Master Controller (VCMI) board serves as the communication interface between the controller and the I/O board, as well as the communication interface with the IONet system control network. It acts as the VME bus master in the control and I/O rack, managing the ids of all boards and their associated terminal boards in the rack.
Power status feedback: Through the J301 backplane connector, the VCMI card receives analog and digital feedback of the power status.
Panel connection: The front panel of the board has four-port connections, including three IONet connectors and a serial port. Three LED indicators are located above each IONet connector, labeled “TX,” “RX,” and “CD.” The panel is attached to the motherboard using screws.
Indicators: In addition to the LED indicators on the IONet connector, the board contains four leds labeled 1, 2, 4, and 8, as well as leds labeled Run/Fail/Status (located above the button reset switch).
Multiple applications: Although mainly used in gas turbine control systems, the IS210AEAAH1B can also be used in other fields, such as robotics, new energy, 3C, electronic equipment, advertising spray engraving equipment, laser equipment, electronic processing, labeling machines, wire equipment, CNC machine tools, LED equipment, printing machinery and food production lines.
