ABB has an extensive product line that includes a full range of power and distribution transformers, high, medium and low voltage switchgear products, AC and DC power transmission and distribution systems, power automation systems, a wide range of measurement devices and sensors, real-time control and optimisation systems, robotics hardware and software and simulation systems, energy-efficient motors and drives, power quality, conversion and synchronisation systems, fusing and switching devices for the safety of power systems. These products are used in a wide range of industrial, commercial, power and utility applications.
Power Systems Division: The Power Systems Division offers a complete range of systems and services for transmission and distribution networks and power plants worldwide, with a focus on substations and substation automation systems. In addition, the division offers Flexible AC Transmission Systems (FACTS) and High Voltage Direct Current (HVDC) transmission systems as well as grid management systems. In the Power Generation business area, the Power Systems Division offers instrumentation products as well as control and auxiliary devices for power plants.
ABB 216NG63
ABB 216VC62a
ABB 216EA61b
ABB 216AB61
ABB 216DB61
ABB REG216
BENTLY 3500/15 127610-01
BENTLY 3500/20 125744-02
BENTLY 3500/42M 140734-02
BENTLY 3500/34 125696-01
BENTLY 3500/25 125792-01
BENTLY 3500/92 136180-01
G3EA HENF315754R1
E3EC HENF315125R1
B5EEd HENF105082R4
Discrete Automation and Motion Control: The Discrete Automation and Motion Control segment supplies products, solutions and services that help customers improve productivity and energy efficiency. Its motors, generators, drive systems, programmable logic controllers, power electronics and robotics products are used in a wide range of automation applications in the areas of power, motion and control. The business segment’s leadership in the wind turbine industry and its growing product line in the solar sector will further contribute to the development of the existing skills, channels and operating platforms of the Discrete Automation & Motion Control division in the industrial sector.
Power electronics: SYNCHROTACT contemporaneous equipment, control systems.
Control systems: 800xA, Advant open control system with Master software, Advant open control system with MOD 300 software, Freelance, Melody series, SATT, Symphony DCI series, Symphony Harmony INFI 90 series, Compact 800
The AC800M controller can be programmed and configured using Compact Control Builder programming software, which allows the AC800M controller to be used for a variety of control applications. The functional features of reusable code and library files also make it easier to configure and build applications for the AC800M.
From basic logic operations to advanced control or both, from a small number of I/O points to applications with thousands of points, from local to remote installations, the AC800M can handle it all.
One of the common features of the AC800M module is its low power consumption, which makes heat dissipation virtually irrelevant and allows for easy and compact installation. In most cases, AC800M controllers can be installed hermetically in cabinets without fans, openings, air filtration and similar equipment. As a result, many potential failure factors are eliminated, ensuring high reliability of the controller.
AC800M controller performance
-Integrated power supply unit, CPU processor and memory on the CPU board
-Five different controller types to choose from
-They are PM851, PM856, PM860, PM861, PM864 and PM865
-Memory storage for operating firmware, control unit hardware configuration information and applications
-Supports 12 fieldbus modules for expansion
-Integrated 2 Ethernet interfaces, 2 RS232C interfaces, ModulBus electrical and fibre optic expansion interfaces
Support for redundancy to reduce point-of-failure errors and ensure efficient control system operation
-Up to 16 tasks, minimum task cycle 1ms, SOE sequential event resolution <1ms
CPU can communicate at controller level via Ethernet interface, 2 Ethernet ports can be set up for redundancy and built-in redundancy switchover program for increased system reliability
As an important component of the control network, the AC800M controller supports both redundant and non-redundant operating modes and two client/server communication service modes. As a client service it enables communication between controllers and with the engineer station software. The OPC Server service also enables data communication with third party software and systems such as HMIs.
The AC800M controller supports a wide range of currently used communication protocols including MasterBus 300, COMLI, Modbus and Siemens 3964R, allowing easy communication with other controllers, automation systems and field devices. external devices.
