AC800M controller performance
-Integrated power supply unit, CPU processor and memory on CPU board
-Five different controller types for users to choose from
-PM851, PM856, PM860, PM861, PM864, PM865 respectively
-Memory storage for operating firmware, control unit hardware configuration information and applications
-Support 12 fieldbus modules expansion
-Integrated 2 Ethernet interfaces, 2 RS232C interfaces, ModulBus electrical and fiber optic expansion interfaces
Supports redundancy settings to reduce point-of-failure errors and ensure control system operational efficiency
-Up to 16 tasks, minimum task cycle 1ms, SOE sequential event resolution <1ms
CPU can realize controller level communication through Ethernet interface, 2 Ethernet ports can be set as redundant, and built-in redundancy switching program is used to improve system reliability.
Communication
| PM851AK01 | 3BSE066485R1 |
| PM856AK01 | 3BSE066490R1 |
| PM858K01 | 3BSE082895R1 |
| PM858K02 | 3BSE082896R1 |
| PM860AK01 | 3BSE066495R1 |
| PM862K01 | 3BSE076940R1 |
| PM862K02 | 3BSE081636R1 |
| PM866AK01 | 3BSE076939R1 |
| PM866AK02 | 3BSE081637R1 |
| PM891K01 | 3BSE053241R1 |
| PM891K02 | 3BSE053242R1 |
| SB822 | 3BSE018172R1 |
| PM857K01 | 3BSE088385R1 |
| PM857K02 | 3BSE088386R1 |
| PM863K01 | 3BSE088381R1 |
| PM863K02 | 3BSE088382R1 |
| PM867K01 | 3BSE076355R1 |
| PM867K02 | 3BSE081638R1 |
| SM811K01 | 3BSE018173R1 |
| SM812K01 | 3BSE072270R1 |
Характеристики контроллера AC800M
-Встроенный блок питания, процессор CPU и память на плате CPU
-Пять различных типов контроллеров на выбор пользователей
-PM851, PM856, PM860, PM861, PM864, PM865 соответственно.
-Память для хранения операционной микропрограммы, информации об аппаратной конфигурации блока управления и приложений.
-Поддержка расширения 12 модулей полевой шины
-Встроенные 2 интерфейса Ethernet, 2 интерфейса RS232C, электрические и оптоволоконные интерфейсы расширения ModulBus.
Поддерживает настройки резервирования для снижения ошибок в точках отказа и обеспечения эффективности работы системы управления
-До 16 задач, минимальный цикл задачи 1 мс, разрешение последовательных событий SOE <1 мс
CPU может осуществлять связь на уровне контроллера через интерфейс Ethernet, 2 порта Ethernet могут быть установлены как резервные, а встроенная программа переключения резервирования используется для повышения надежности системы.
| CI853K01 | 3BSE018103R1 |
| CI867K01 | 3BSE043660R1 |
| CI867AK01 | 3BSE092689R1 |
| CI854BK01 | 3BSE069449R1 |
| CI871K01 | 3BSE056767R1 |
| CI871AK01 | 3BSE092693R1 |
| CI860K01 | 3BSE032444R1 |
| CI868K01 | 3BSE048845R1 |
| CI868AK01 | 3BSE092691R1 |
| CI873K01 | 3BSE056899R1 |
| CI873AK01 | 3BSE092695R1 |
| CI869K01 | 3BSE049110R1 |
| CI855K01 | 3BSE018106R1 |
| C1856K01 | 3BSE026055R1 |
| CI865K01 | 3BSE040795R1 |
| CI857K01 | 3BSE018144R1 |
| CI858K01 | 3BSE018135R1 |
There are two types of connections between controllers and I/Os:
-Local I/O: using Modulebus (electrical/fiber optic) communication lines, with a maximum of 8* local I/O stations per controller;
-Remote I/O: remote I/O connection using Profibus DP fieldbus extension, supporting a maximum of 98 remote stations;
-Longest distance Cable 500m (500Kb/s)
-Multimode fiber 2KM (12Mb/s)
* Non-redundant for 8 local I/O stations
Redundant for 7 I/O stations
As an important component of the control network, the AC800M controller supports two modes of operation, redundant and non-redundant, and two modes of communication services, client/server. The client service enables communication between controllers and with the engineer station software. The OPC Server service also enables data communication with third party software and systems such as HMI.
The AC800M controller supports a variety of popular communication protocols including MasterBus 300, COMLI, Modbus, and Siemens 3964R, allowing easy communication with other controllers, automation systems, and field devices. external devices.
