PKGD (3) SGCT MATCHED SET 800A
Rockwell Automation 81001-450-53-R PKGD (3) SGCT MATCHED SET 800A
Rockwell Automation 81001-450-53-R PKGD (3) SGCT MATCHED SET 800A
80025-523-09-R
80026-508-03-R
81001-408-52-R
81001-956-52-R
81004354-55
81000-671-01-R
81001-956-52-R
Thyristor modules, also known as power semiconductor modules, are commonly used in the field of power electronics technology. It is a high-power semiconductor device with a modular package and a four-layer structure of three PN junctions.
From the internal package chip, thyristor module can be divided into two categories: controllable module and rectifier module. From the specific use of the distinction, thyristor modules can be divided into a variety of types, Such as ordinary thyristor module (MTC\MTX\MTK\MTA), ordinary rectifier module (MDC), ordinary thyristor, commutator mixed module (MFC), fast thyristor, commutator and mixed module (MKC\MZC), non-insulated thyristor, commutator and mixed module (also known as welding machine special module MTG\MD) G), three-phase rectifier bridge output thyristor module (MDS), single-phase (three-phase) rectifier bridge module (MDQ), single-phase half-controlled bridge (three-phase fully controlled bridge) module (MTS) and Schottky module.
In addition, thyristor modules can also be used in a variety of specific devices and applications, such as rotation controllers. In the rotation controller, the thyristor module (such as the MTC module) and the RCV rotation controller are integrated together for the rotation control of the crane. The module has the advantages of small size, light weight, high voltage resistance, large capacity, high efficiency, sensitive control, long service life, strong overload capacity and anti-interference ability, simple control circuit and so on. It is mainly used for controllable rectification, inverter, voltage regulation, contactless switch, etc., and RCV rotary controller supporting the use of adjustable three-phase electric speed, widely used in all kinds of mechanical equipment using motor speed regulation.
