SCXI-1160 16-channel universal relay switch module
The SCXI-1160 is a 16-channel universal relay switch module. The module has the following features:
Independent single-pole Double-throw (SPDT) latching relays: Each channel is equipped with an independent SPDT latching relay, also known as a Form C, which has extremely low on-resistance and low thermal offset.
High switching performance: The module has a maximum switching rate of 50 operations per second and can be controlled through software programming.
Wide range of applications: The SCXI-1160is suitable for switching state control of a wide range of industrial equipment, including test and measurement systems, PLCS and DCS systems.
Compatibility with other SCXI modules: This module can be combined with NI’s other SCXI modules for more complex measurement and control applications.
Power Supply and operating environment: The SCXI-1160requires a power supply of +8-30 VDC with a maximum power consumption of 2.8 W and an operating temperature range of 0-55°C.
Physical specifications: 3.81cm x 17.78cm x 10.16cm, weight 0.18kg.
The SCXI-1160 is a powerful multichannel switching module for switching, routing and controlling medium-level signals for a variety of automated control and signal switching applications. SCXI-1160 is a multi-functional relay switch module that is widely used in many fields. Its main application areas include:
Automated testing: The SCXI-1160 can be used to control and switch test equipment and signal sources to achieve automated control of the test system.
Industrial control: The module can control the switching status of various industrial equipment to achieve automatic control of industrial processes, suitable for industrial process monitoring, production testing and other scenarios.
Data Acquisition: The SCXI-1160 is capable of multi-channel measurement and data acquisition for applications requiring high bandwidth and real-time data logging.
Machine vision: In some automated testing and industrial control, the SCXI-1160 can be used in combination with machine vision systems to improve production efficiency and quality.
Motion control: This module can drive solenids, valves, relays, actuators, etc., for complex motion control systems.
Environmental monitoring: The SCXI-1160 can be used in environmental monitoring systems to monitor and regulate environmental parameters by controlling sensors and actuators.
Laboratory measurements: In a laboratory environment, the SCXI-1160 can be used for signal routing and multi-channel measurements to support a variety of scientific experiments and research.
In addition, the SCXI-1160 features low thermal offset and low on-resistance, making it suitable for medium-level signal switching and routing where high reliability and precise control are required. These characteristics make it widely used in many industries such as electronics, energy, industrial machinery, life sciences, semiconductors and transportation.
